| Parameters | Details & Options |
|---|---|
| 1) Size: | MOQ is 100 sqm, width x length x eave height, roof slope |
| 2) Span: | 9-180m, type: single slope, double slope, multi slope; single span, double span, multi span; single floor, double floor, multi floors |
| 3) Height: | 6-24m |
| 4) Slope: | 1/20, 1/10, 1/5, 1/3 |
| 5) Column distance: | 6-10m |
| 6) Base: | Cement and steel foundation bolts |
| 7) Column and beam: | Material Q345(S355JR) or Q235(S235JR) steel, all bolts connection. Straight cross-section or Variable |
| 8) Bracing: | X or V or other type bracing made from angle, round pipe, etc. |
| 9) C or Z purlin: | Size from C120~C320, Z100~Z200 |
| 10) Roof and wall panel: | Single colorful corrugated steel sheet 0.2~1.2mm thick, such as YX25-207-828 or sandwich panel: sandwich panel with EPS, ROCK WOOL, PU etc. insulation thickness around 50mm~150mm, YX40-320-960 |
| 11) Accessories: | Semi-transparent skylight belts, Ventilators, down pipe, outer gutter, etc. |
A: We have our own manufacturing factories for steel structures, steel sheets, and sandwich panels. You are welcome to visit our manufacturing facilities to see our products and discuss your project.
A: We provide installation guidance service based on requests. The shop drawings, installation drawings, and videos will be sent to help with the site erection. If required, our engineers can guide the installation on-site.
A: It depends on the order quantities. Generally, the delivery time will be within 25 to 60 days.
A: Please submit your building requirements to us. We will analyze your specifications and provide a detailed quote as soon as possible.
A: Yes, we can design diverse structural drawings based on your requirements. By utilizing AutoCAD, Tekla Structures, SAP2000, and STAAD Pro, we design functional buildings such as warehouses, workshops, offices, schools, apartments, and exhibition halls.
A: The steel structure material is packed on steel pallets. After loading into the containers, they are dispatched to the port for sea transportation.
